Eaton LG3600S02 600A 3P Generator Molded Case Circuit Breaker – Bolt-On – 600VAC

The Eaton LG3600S02 molded case generator circuit breaker is designed to deliver reliable protection and operational control for generator-based power distribution systems. Built on Eaton’s durable LG frame platform, this breaker incorporates an electronic interchangeable trip unit with an adjustable trip range of 500–2500, allowing flexible configuration to match varying load and protection requirements. Rated at 600 amperes at 40°C and configured with three poles, the LG3600S02 is suitable for demanding commercial and industrial generator applications. The S02 configuration includes a factory-installed 12–24 VAC or VDC shunt trip mounted on the left pole with wiring exiting from the rear, enabling efficient remote tripping capability and streamlined panel integration. This model is supplied with standard line and load terminals to support secure and reliable electrical connections.

Product Specification

• LG Frame Style Molded Case Generator Circuit Breaker
• Electronic Interchangeable Trip Unit
• Adjustable Trip Range: 500–2500
• Rated Current: 600A at 40°C
• 3 Pole Configuration
• S02 Configuration with Factory Installed Shunt Trip
• Line and Load End Terminals Standard

Technical Specification

• Electronic trip unit for accurate overload and short-circuit protection
• Interchangeable trip unit design for adaptable protection settings
• 12–24 VAC or VDC shunt trip enabling remote circuit interruption
• Shunt trip mounted on the left pole with wiring exiting from the rear
• Bolt-On connection design for stable and secure installation
• Rugged molded case construction engineered for generator protection systems

Voltage and Ratings

• Rated Voltage: 600VAC @ 50/60Hz
• Interrupting Capacity:
• • 18 kA @ 240VAC
  • 14 kA @ 480VAC
  • 10 kA @ 600VAC

Product Data

• Manufacturer: Eaton / Cutler-Hammer
• Warranty: One Year
• Frame Type: L
• Amperage Rating: 600A
• Poles: 3
• Maximum Voltage: 600V
• Connection Type: Bolt-On
• Trip Setting Range: 500–2500
• Configuration: S02 – 12–24 VAC/VDC Shunt Trip, Left Pole Mounted, Exiting Rear
• Standard Lug Type: Line and Load
