Eaton NGC312036EC Series G Electronic Molded Case Circuit Breaker – 1200A, 3-Pole, 480 Vac, 200 kAIC

The Eaton NGC312036EC Series G electronic molded case circuit breaker is designed for high-capacity protection in demanding commercial and industrial power distribution systems. Equipped with an electronic trip unit, it provides precise circuit protection against overloads and short circuits while supporting reliable operation in high-fault current environments. Built on the NG-frame Series G platform, this breaker is 100% rated, HACR rated, and suitable for reverse feed applications.

Electrical Ratings

• Current Rating: 1200A
• Voltage Rating: 480 Vac
• Frequency Rating: 50/60 Hz
• Number of Poles: Three-pole
• Interrupt Rating: 200 kAIC at 240 Vac / 100 kAIC at 480 Vac
• Trip Type: T172
• Circuit Breaker Type: NG
• Frame: NG
• Rating: 100% rated

Key Specifications

• Manufacturer: Eaton
• Catalog Number: NGC312036EC
• UPC: 786685574455
• Product Type: Electronic molded case circuit breaker
• Series: Series G
• Terminals: Line and load
• Mounting Hardware: Imperial
• Standards: UL Listed, CSA Certified
• Compliances: HACR Rated
• Catalog Notes: All Eaton NG-Frame circuit breakers are suitable for reverse feed use. Breakers do not ship with lugs.
• Warranty: Eaton Selling Policy 25-000

Physical Details

• Product Length/Depth: 6 in
• Product Height: 9 in
• Product Width: 9 in
• Product Weight: 48 lb

Product Data

• Application: Commercial and industrial electrical distribution systems
• Installation Use: High-capacity Series G breaker assemblies and power distribution equipment
• Function: Provides advanced electronic overload and short-circuit protection for electrical circuits
• System Compatibility: Designed for Eaton NG-frame Series G distribution systems
• Safety Feature: High interrupting capacity and electronic trip protection ensure dependable fault clearing in critical installations
