Eaton P3F326RGN Pow-R-Way III Fusible Plug-In Unit – 600A, 3-Pole, 120/208V, R-Class Fuse
Couldn't load pickup availability
Ask an expert
The Eaton P3F326RGN Pow-R-Way III fusible plug-in unit is designed for use in busway power distribution systems requiring high-capacity, reliable circuit protection. It utilizes R-class fusing to deliver effective overcurrent protection and is engineered for secure plug-in installation within Eaton Pow-R-Way III busway assemblies. This unit is suitable for demanding commercial and industrial applications where safe and efficient busway power distribution is required.
Electrical Ratings
- Current Rating: 600A
- Voltage Rating: 120/208 V
- Number of Poles: Three-pole
- Fuse Type: R-class
- Type: Fusible plug-in unit
Key Specifications
- Manufacturer: Eaton
- Catalog Number: P3F326RGN
- UPC: 786683021289
- Product Type: Fusible plug-in unit
- Design Series: Pow-R-Way III
- Standards: UL 857, CSA Certified, ANSI, IEEE Certified, NEMA Compliant
- Warranty: Eaton Selling Policy 25-000
Physical Details
- Product Length/Depth: 10.59 in
- Product Height: 48.9 in
- Product Width: 26.31 in
- Product Weight: 82 lb
Product Data
- Application: Busway power distribution systems
- Installation Use: Plug-in unit for Pow-R-Way III busway assemblies
- Grounding Options: 50% internal
- Neutral Options: 100%
- Type plug
- Vendor Eaton Cutler-Hammer
- Brand Eaton
