The Eaton QBGFEP1030 bolt-on circuit breaker provides dependable 30A, 1-pole GFCI protection for 120V circuits. Designed for Eaton QB load centers, this breaker features 30 mA ground-fault sensitivity and an integrated bell alarm for enhanced safety and monitoring in residential and commercial applications.
Voltage and Rating
- Amperage: 30 Amps
- Poles: 1-Pole
- Voltage Rating: 120 Volts AC
- Interrupting Capacity: 10 kAIC
- Trip Sensitivity: 30 mA
Key Specifications
- Breaker Type: Ground-Fault Circuit Interrupter (GFCI)
- Mounting Type: Bolt-On
- Product Range: QB
- Application: Ground-fault protection for branch circuits
- Special Features: Bell alarm
- Compatible Panels: Eaton QB load centers
Technical Specifications
- Wire Size Range: (1) #14–4 AWG Cu/Al
- Connection Terminals: Cable-in/cable-out
- Terminal Tightening Torque: 45 lb-in
- Certifications: UL 943 Listed, HACR Rated
Product Data
- Manufacturer: Eaton
- Brand: Eaton
- Model Number: QBGFEP1030
- UPC: 786679415061
Dimensions
-
- Height: 1.1 in
- Width: 3.3 in
- Depth: 5.1 in
- Weight: 0.5 lbs
