Eaton

Eaton QCF2030 30A 2-Pole Thermal-Magnetic Circuit Breaker – Cable-In/Cable-Out – 120/240V

In stock
SKU: QCF2030 GTIN/UPC: 786679143346
$52.50

Select product select item condition:

SELECT ITEM CONDITION
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
10 day returns

Ask an expert

Email 866-972-6370

The Eaton Quicklag QCF2030 is a 30 Amp, 2-pole thermal-magnetic circuit breaker designed to provide reliable protection for 120/240V electrical systems in Quicklag loadcenters. Featuring a cable-in/cable-out connection design and front mounting, it ensures straightforward installation and dependable performance. With a 10 kA interrupting capacity, this breaker delivers effective overload and short-circuit protection, making it suitable for residential and light industrial applications.

Electrical Ratings:

  • Amperage: 30 Amps
  • Voltage: 120/240V AC
  • Interrupt Rating: 10 kAIC

Key Specifications:

  • Breaker Type: Thermal-Magnetic
  • Poles: 2-Pole
  • Product Range: Quicklag
  • Mounting Mode: Front
  • Terminal Type: Cable-In/Cable-Out
  • Application: Residential and light industrial circuit protection

Technical Specifications:

  • Wire Size: (1) #14–4 AWG Cu/Al
  • Tightening Torque: 35.4 lb-in
  • Certifications: UL Listed, CSA Certified

Product Data:

  • Manufacturer: Eaton
  • Brand: Eaton
  • Model Number: QCF2030
  • UPC: 786679143346
  • Dimensions: 1.1" H × 3.1" W × 4.6" D
  • Weight: 0.500 lbs
  • Type Circuit Breakers
  • Vendor Eaton
  • Brand Eaton
