Eaton XTCE012B10T IEC Contactor – 12A, 3-Pole, 24V AC Coil, 45 mm Frame, Non-Reversing

The Eaton XTCE012B10T is an IEC-rated XT Series contactor designed for reliable switching and control of electrical loads in industrial and commercial motor control applications. It operates as a full voltage non-reversing contactor, providing dependable performance for motor starting and power switching. Its compact 45 mm frame design makes it suitable for space-efficient installation in control panels and starter assemblies.

Electrical Ratings

• Continuous Current Rating: 12 A
• Amperage Rating: 12 A
• Coil Voltage: 24 Vac (50/60 Hz)
• Frequency Rating: 50/60 Hz
• HP Rating (Max):
  • 1 HP (115 V, 1-phase)
  • 2 HP (200–230 V, 1-phase)
  • 10 HP (200–230 V, 3-phase)
  • 10 HP (460–575 V, 3-phase)

Key Specifications

• Manufacturer: Eaton
• Catalog Number: XTCE012B10T
• EAN: 4015082768348
• Product Type: Contactor
• Series: XT IEC
• Frame Size: 45 mm
• Operation Type: Non-reversing
• Number of Poles: Three-pole
• Contact Configuration: 1 NO
• Terminals: Screw terminals
• Compliance: RoHS Compliant, CE Marked
• Certifications: UL Listed, CSA Certified, IEC 60947, EN 60947

Physical Details

• Product Length/Depth: 4.93 in
• Product Height: 2.68 in
• Product Width: 1.77 in
• Product Weight: 0.5 lb

Product Data

• Application: Motor control and electrical load switching
• Installation Use: Industrial motor starters and control panels
• Function: Provides full voltage non-reversing switching for motors and loads
• System Compatibility: Eaton XT IEC motor control systems
• Safety Feature: Ensures reliable switching performance under IEC-compliant standards
