Eaton XTCE065DS1B IEC Contactor – 65A, 3-Pole, 220–240V Coil, 55 mm Frame, Non-Reversing

The Eaton XTCE065DS1B is an IEC-rated XT Series contactor designed for reliable switching of motors and electrical loads in industrial and commercial applications. It operates as a full voltage non-reversing contactor and is suitable for use in motor starters, control panels, and power switching systems requiring higher current capacity. Its 55 mm frame construction provides durability and standardized IEC compatibility for industrial installations.

Electrical Ratings

• Continuous Current Rating: 65 A
• Amperage Rating: 65 A
• Coil Voltage: 220–240 Vac (50/60 Hz)
• Frequency Rating: 50/60 Hz
• HP Rating (Max):
  • 5 HP (115 V, 1-phase)
  • 10 HP (200–230 V, 1-phase)
  • 15 HP (230 V, 3-phase)
  • 20 HP (200–230 V, 3-phase)
  • 25 HP (460 V, 3-phase)
  • 50 HP (575 V, 3-phase)

Key Specifications

• Manufacturer: Eaton
• Catalog Number: XTCE065DS1B
• UPC: 786685365237
• Product Type: Contactor
• Series: XT IEC
• Frame Size: 55 mm
• Operation Type: Non-reversing
• Number of Poles: Three-pole
• Contact Configuration: 1 NO, 1 NC
• Terminals: Screw terminals
• Certifications: UL Listed, CSA Certified, IEC 60947, EN 60947

Physical Details

• Product Length/Depth: 1 in
• Product Height: 1 in
• Product Width: 1 in
• Product Weight: 1 lb

Product Data

• Application: Motor control and electrical load switching
• Installation Use: Industrial motor starters and control panels
• Function: Provides reliable full voltage switching for motors and loads
• System Compatibility: Eaton XT IEC contactor systems
• Safety Feature: Ensures dependable switching performance under IEC-compliant standards
