Siemens ED63A005 5 Amp Motor Circuit Protector – 3 Pole – 600 V – 25 kA@480 V – Bolt-On – SENTRON Series

The Siemens ED63A005 is a 5 Amp, 3-pole Motor Circuit Protector (MCP) from the Siemens SENTRON Series, Type ED. It is rated for 600 V with a 25 kA interrupting rating at 480 V and provides instantaneous-only magnetic protection. The breaker features a magnetic adjustment range of 16–54 A and is designed for bolt-on mounting. Lugs are not included.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Motor Circuit Protector (MCP)
• Series: SENTRON
• Type: ED
• Catalog Number / MPN: ED63A005
• Primary Rating: 5 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 25 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Type: Magnetic-Only
• Trip Functions: I – Instantaneous Protection Only
• Magnetic Range: 16–54 A
• Connection / Mounting: Bolt-On
• Terminals: Lugs Not Included
• Protection Type: Motor Circuit Protector (MCP)

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: ED63A005
• Series: SENTRON
• Type: ED
• Current Rating: 5 A
• Pole Count: 3 Pole
• Product Type: Motor Circuit Protector (MCP)
• Trip Function: I – Instantaneous Protection Only
• Trip Type: Magnetic-Only
• Magnetic Range: 16–54 A
• UPC: 783643210813

Compatibility

The Siemens ED63A005 is designed for compatible Siemens SENTRON Series Type ED motor circuit protection applications. Verify the specific panelboard or motor control equipment, system voltage, mounting configuration, and breaker compatibility before installation.
