Siemens ED63S100A 100 Amp Molded Case Switch – 3 Pole – 600 V – 25 kA@480 V – Plug-In – ED Series

The Siemens ED63S100A is a 100 Amp, 3-pole molded case plug-in switch from the Siemens ED Series. It has a maximum voltage rating of 600 V and a standard interrupting rating of 25 kA at 480 V. The switch includes Long-Time and Instantaneous protection functions and is designed for bolt-on plug-in installation.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Molded Case Switch
• Series: ED
• Catalog Number / MPN: ED63S100A
• Primary Rating: 100 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V Maximum
• Interrupting Rating: 25 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Functions: Long-Time and Instantaneous
• Connection / Mounting: Bolt-On Plug-In

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: ED63S100A
• Series: ED
• Current Rating: 100 A
• Pole Count: 3 Pole
• Product Type: Molded Case Switch
• Trip Functions: Long-Time and Instantaneous
• Connection / Mounting: Bolt-On Plug-In
• UPC: 783643211056

Compatibility

The Siemens ED63S100A is designed for compatible Siemens ED Series electrical distribution applications with bolt-on plug-in mounting. Verify the specific panelboard, system voltage, mounting configuration, and switch compatibility before installation.
