Eaton EDB3100L Molded Case Circuit Breaker – 100A – 3-Pole / 3-Phase – 240V AC – 22kAIC @ 240V – Line & Load – Series C ED

The Eaton EDB3100L is a 100A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series C Type ED. It is a complete F-frame breaker featuring fixed thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The EDB3100L is rated for 240V AC and 125V DC and provides a 22kAIC interrupting rating at 240V AC. It features line- and load-side connections and operates at 50/60Hz.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Name: Series C Complete Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: ED
• Frame: F-Frame
• Catalog No.: EDB3100L
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 125V DC
• Interrupting Rating: 22kAIC @ 240V AC
• Trip Type: Fixed Thermal, Fixed Magnetic
• Connection: Line and Load
• Frequency: 50/60Hz
• Breaker Configuration: Complete Breaker
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDB3100L
• Catalog Number: EDB3100L
• Model: EDB3100L
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: ED
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 100A
• Trip Configuration: Fixed Thermal / Fixed Magnetic
• UPC:782116976133

Compatibility:

Designed for use with compatible Eaton Series C Type ED F-frame electrical distribution equipment that accepts ED Series molded case circuit breakers. The EDB3100L provides 100A, 3-pole thermal-magnetic overcurrent protection for compatible 240V AC electrical distribution applications.

The breaker features fixed thermal and fixed magnetic trips, line- and load-side connections, and a 22kAIC interrupting rating at 240V AC. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, terminal requirements, and installation requirements before installation.
