Eaton EDB3150L Molded Case Circuit Breaker – 150A – 3-Pole / 3-Phase – 240V AC – 22kA @ 240V – Not Specified – Series C ED

The Eaton EDB3150L is a 150A, 3-pole molded case circuit breaker from the Eaton Series C Type ED F-Frame. It is supplied as a complete breaker with fixed thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The EDB3150L is rated for 240V AC and 125V DC and provides a 22kA interrupting rating at 240V AC. It features line- and load-side connections and operates at 50/60 Hz.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: ED
• Frame: F-Frame
• Catalog No.: EDB3150L
• Current Rating: 150A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 125V DC
• Interrupting Rating: 22kAIC @ 240V AC
• Protection Type: Thermal-Magnetic
• Trip Type: Fixed Thermal, Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Connection: Line and Load
• Frequency: 50/60 Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDB3150L
• Catalog Number: EDB3150L
• Model: EDB3150L
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: ED
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 150A
• Trip Configuration: Fixed Thermal, Fixed Magnetic
• UPC:782116976157

Compatibility:

Designed for use with compatible Eaton Series C Type ED F-Frame electrical distribution equipment that accepts ED Series molded case circuit breakers. The EDB3150L provides 150A, 3-pole thermal-magnetic overcurrent protection for compatible 240V AC applications.

The breaker is supplied as a complete breaker with fixed thermal and fixed magnetic protection and line- and load-side connections. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, connection requirements, and installation specifications before installation.

Certifications:

• Series C ED Series
• F-Frame
• 150A Rated
• 3-Pole / 3-Phase
• 240V AC Rated
• 125V DC Rated
• 22kAIC @ 240V AC Interrupting Rating
• Fixed Thermal Protection
• Fixed Magnetic Protection
• Complete Breaker
• Line and Load Connections
• 50/60 Hz
