Eaton EDB3175L 175 Amp Molded Case Circuit Breaker – 3 Pole – 240 V AC / 125 V DC – 22 kA@240 V AC – F-Frame – Series C

The Eaton EDB3175L is a 175 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer Series C, Type ED, F-Frame product range. It is rated for 240 V AC and 125 V DC, providing a 22 kA interrupting rating at 240 V AC.

This complete breaker features a fixed thermal and fixed magnetic trip mechanism for circuit protection. It includes line- and load-side connections and operates at a frequency of 50/60 Hz.

Specifications

• Manufacturer: Eaton
• Brand: Eaton / Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: ED
• Frame: F-Frame
• Catalog Number / MPN: EDB3175L
• Primary Rating: 175 Amp
• Poles / Configuration: 3 Pole
• AC Voltage: 240 V AC
• DC Voltage: 125 V DC
• Interrupting Rating: 22 kAIC @ 240 V AC
• Trip Type: Fixed Thermal / Fixed Magnetic
• Connection: Line and Load
• Frequency: 50/60 Hz
• Assembly: Complete Breaker

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton / Cutler-Hammer
• Catalog Number: EDB3175L
• Series: Series C
• Type: ED
• Frame: F-Frame
• Current Rating: 175 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Trip Mechanism: Fixed Thermal / Fixed Magnetic
• Connection: Line and Load
• UPC:782116976164

Compatibility

The Eaton EDB3175L is intended for compatible Eaton / Cutler-Hammer Series C F-Frame electrical distribution applications.
