Eaton EDB3225L Molded Case Circuit Breaker – 225A – 3-Pole / 3-Phase – 240V AC – 22kAIC @ 240V – Line & Load – Series C ED F-Frame

The Eaton EDB3225L is a 225A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series C ED Series, utilizing an F-Frame. It is a complete breaker designed for compatible electrical distribution applications and provides fixed thermal and fixed magnetic trip protection.

The EDB3225L is rated for 240V AC and 125V DC and provides a 22kA interrupting rating at 240V AC. It features line- and load-side connections and operates at 50/60 Hz.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: ED
• Type: ED
• Frame: F-Frame
• Catalog No.: EDB3225L
• Current Rating: 225A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 125V DC
• Interrupting Rating: 22kAIC @ 240V AC
• Protection Type: Thermal-Magnetic
• Trip Type: Fixed Thermal, Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Connection Type: Line and Load
• Frequency: 50/60 Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDB3225L
• Catalog Number: EDB3225L
• Model: EDB3225L
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: ED
• Type: ED
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 225A
• Rated Current: 225A
• Rated Voltage: 240V AC
• Trip Configuration: Fixed Thermal / Fixed Magnetic
• UPC:782116976188

Compatibility:

Designed for use with compatible Eaton Series C ED Series F-Frame electrical distribution equipment that accepts ED Series molded case circuit breakers. The EDB3225L provides 225A, 3-pole thermal-magnetic overcurrent protection for compatible 240V AC applications.

The breaker is a complete breaker with fixed thermal and fixed magnetic protection and line- and load-side connections. It also carries a 125V DC rating and operates at 50/60 Hz. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C ED Series
• F-Frame
• 225A Rated
• 3-Pole / 3-Phase
• 240V AC Rated
• 125V DC Rated
• 22kAIC @ 240V AC Interrupting Rating
• Thermal-Magnetic Protection
• Fixed Thermal Trip
• Fixed Magnetic Trip
• Complete Breaker
• Line and Load Connections
• 50/60 Hz
