Square D EDB36090 Molded Case Circuit Breaker – 90A – 3-Pole / 3-Phase – 600Y/347V AC – Key Capacity Not Specified – Bolt-On – EDB Series

The Square D EDB36090 is a 90A, 3-pole, 3-phase bolt-on molded case circuit breaker from the Square D / Schneider Electric EDB Series. It is designed for use in compatible Square D NF Panelboards and provides thermal-magnetic overcurrent protection.

The EDB36090 is rated for 600Y/347V AC and features a thermal-magnetic trip unit with a signal indicator that provides indication when a trip has occurred. The breaker is calibrated for operation at 40°C and is available with aluminum lugs supporting specified copper and aluminum conductor ranges.

The available information also identifies the breaker as CSA-rated, HID-rated, HACR-rated, and UL Listed as High-Intensity Discharge.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: EDB
• Series: EDB
• Catalog No.: EDB36090
• Current Rating: 90A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600Y/347V AC
• Protection Type: Thermal-Magnetic
• Trip Unit: Thermal-Magnetic
• Mounting Type: Bolt-On
• Trip Indication: Signal Indicator
• Hold Current: 270A
• Trip Current: 875A
• Temperature Calibration: 40°C
• Lug Material: Aluminum
• Aluminum Conductor Range: AWG 12–6
• Copper Conductor Range: AWG 14–6
• Application: Square D NF Panelboards and Electrical Distribution
• Ratings: CSA, HID, and HACR Rated
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDB36090
• Catalog Number: EDB36090
• Model: EDB36090
• Product Family: Square D EDB Circuit Breakers
• Series: EDB
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 90A
• UPC:785901235521

Compatibility:

Designed for use with compatible Square D NF Panelboards that accept EDB Series bolt-on molded case circuit breakers. The EDB36090 provides 90A, 3-pole thermal-magnetic protection for compatible 600Y/347V AC electrical distribution applications.

The breaker uses aluminum lugs and accommodates AWG 12–6 aluminum conductors and AWG 14–6 copper conductors. Always verify the specific panelboard model, approved breaker type, system voltage, conductor material and size, terminal requirements, trip characteristics, and installation specifications before installation.

Certifications:

• UL Listed
• UL Listed – High-Intensity Discharge (HID)
• CSA Rated
• HID Rated
• HACR Rated
• 90A Rated
• 3-Pole / 3-Phase
• 600Y/347V AC Rated
• Thermal-Magnetic Protection
• Bolt-On Mounting
• 40°C Calibrated
• Aluminum Lugs
