Eaton EDH3125 Molded Case Circuit Breaker – 125A – 3-Pole / 3-Phase – 240V AC / 125V DC – 100kA @ 240V – Load Side – Series C ED

The Eaton EDH3125 is a 125A, 3-pole molded case circuit breaker from the Eaton Series C F-Frame ED Series. It is supplied as a complete breaker and features fixed thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The EDH3125 is rated for 240V AC and 125V DC and provides a 100kA interrupting rating at 240V AC. It features a load-side connection and is designed for 50/60 Hz operation.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: ED
• Frame: F-Frame
• Catalog No.: EDH3125
• Current Rating: 125A
• Number of Poles: 3-Pole
• Phase: Not specified
• AC Voltage Rating: 240V AC
• DC Voltage Rating: 125V DC
• Interrupting Rating: 100kA @ 240V AC
• Trip Type: Fixed Thermal, Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Connection: Load Side
• Frequency: 50/60 Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EDH3125
• Catalog Number: EDH3125
• Model: EDH3125
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: ED
• Frame: F-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 125A
• UPC:786679455340

Compatibility:

Designed for use with compatible Eaton Series C F-Frame ED electrical distribution equipment that accepts ED Series molded case circuit breakers. The EDH3125 provides 125A, 3-pole overcurrent protection for compatible 240V AC and 125V DC applications.

The breaker is supplied as a complete breaker with fixed thermal and fixed magnetic protection and a load-side connection. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, connection arrangement, mounting requirements, and installation specifications before installation.

Certifications:

• Eaton Series C ED Series
• F-Frame
• 125A Rated
• 3-Pole
• 240V AC Rated
• 125V DC Rated
• 100kA @ 240V AC Interrupting Rating
• Fixed Thermal Protection
• Fixed Magnetic Protection
• Load-Side Connection
• 50/60 Hz
• Complete Breaker
