EGB2020FFG - Cutler Hammer Feed-Thru 480V 20A 2 pole circuit breaker 18kA@480V
Couldn't load pickup availability
Ask an expert
Description
EGB2020FFG
The Cutler Hammer EGB2020FFG is a Molded Case Circuit Breaker. This type EGB circuit breaker is a member of The Series G family. The EGB2020FFG is a 2 pole, 480 Volt, 20 amp rated circuit breaker, with an AIC rating of 18kA@480V. The EGB2020FFG is manufactured by Cutler Hammer. The EGB2020FFG uses a Feed-Thru connection. Includes Thermal Magnetic protection.
Specifications
- Part Number: EGB2020FFG
- Manufacturer : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGB
- Voltage : 480
- Amperage : 20
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 786685018423
- GTIN : 00786685018423
- Country of Origin : Dominican Republic
- Dimensions : Length 2.99in Height 5.5in Width 2in
- Weight : 2
- Certification : CSA Certified,IEC Rated,UL Listed,CE Marked
- Type Circuit Breakers
- Vendor Eaton Cutler-Hammer
- Brand Eaton
- Electrical Rating Feed Thru - 20 Amp - 2 Pole - 480 Volt
