Eaton Series G EGB3032AFG 32 Amp Molded Case Circuit Breaker – 3 Pole – 600Y/347V – 25 kAIC @ 240V / 18 kAIC @ 480V – EG Frame

The Eaton Series G EGB3032AFG is a 32A, three-pole molded case circuit breaker designed for electrical circuit protection in compatible power distribution systems. It features an adjustable thermal and fixed magnetic trip mechanism, providing overload and short-circuit protection.

Specifications

• Brand: Eaton
• Series: Series G
• Frame: EG
• Catalog Number / MPN: EGB3032AFG
• Rated Current: 32A
• Poles: 3 Pole
• Rated Voltage: 600Y/347V AC
• Interrupting Capacity: 25 kAIC @ 240V AC; 18 kAIC @ 480V AC
• Trip Type: Adjustable thermal, fixed magnetic
• Frequency: 50/60 Hz
• Terminals: Line and load
• Configuration: Complete breaker

Part Numbers & Identification

• Manufacturer: Eaton
• Product Family: Cutler-Hammer Series G
• Catalog Number: EGB3032AFG
• Frame Designation: EG
• Product Type: Molded Case Circuit Breaker (MCCB)
• UPC:782114875452

Compatibility

Suitable for Eaton Series G EG-frame applications requiring a 32A, three-pole MCCB with adjustable thermal and fixed magnetic trip protection. It supports compatible systems rated up to 600Y/347V AC.
