Eaton EGB3100FFB Molded Case Circuit Breaker – 100A – 3-Pole / 3-Phase – 600Y/347V AC – 25kA @ 240V / 18kA @ 480V – Bolt-On – Series G EGB

The Eaton EGB3100FFB is a 100A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series G Type EGB EG-Frame. It is supplied as a complete breaker with fixed thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The EGB3100FFB is rated for 600Y/347V AC and provides interrupting ratings of 25kAIC at 240V AC and 18kAIC at 480V AC. It features a bolt-on connection and operates at 50/60Hz.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series G
• Series: Series G
• Type: EGB
• Frame: EG-Frame
• Catalog No.: EGB3100FFB
• Current Rating: 100A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600Y/347V AC
• Interrupting Rating: 25kAIC @ 240V AC; 18kAIC @ 480V AC
• Protection Type: Fixed Thermal, Fixed Magnetic
• Trip Type: Fixed Thermal / Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Mounting / Connection: Bolt-On
• Frequency: 50/60Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EGB3100FFB
• Catalog Number: EGB3100FFB
• Model: EGB3100FFB
• Product Family: Eaton Series G Molded Case Circuit Breakers
• Series: Series G
• Type: EGB
• Frame: EG-Frame
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 100A
• Trip Configuration: Fixed Thermal / Fixed Magnetic
• UPC:786685381664

Compatibility:

Designed for use with compatible Eaton Series G Type EGB electrical distribution equipment that accepts EG-Frame bolt-on molded case circuit breakers. The EGB3100FFB provides 100A, 3-pole protection for compatible 600Y/347V AC electrical distribution applications.

The breaker uses a bolt-on connection and provides fixed thermal and fixed magnetic protection. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, mounting arrangement, trip characteristics, and installation requirements before installation.

Certifications:

• Series G EGB
• EG-Frame
• 100A Rated
• 3-Pole / 3-Phase
• 600Y/347V AC Rated
• 25kAIC @ 240V AC Interrupting Rating
• 18kAIC @ 480V AC Interrupting Rating
• Fixed Thermal Protection
• Fixed Magnetic Protection
• Complete Breaker
• Bolt-On Connection
• 50/60Hz
