Eaton EGB3160AFG Molded Case Circuit Breaker – 160A – 3-Pole / 3-Phase – 600Y/347V AC – 25kAIC @ 240V / 18kAIC @ 480V – Line & Load – Series G EG Frame

The Eaton EGB3160AFG is a 160A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series G EG Frame product family. It is supplied as a complete breaker with adjustable thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The EGB3160AFG is rated for 600Y/347V AC and provides interrupting ratings of 25kAIC at 240V AC and 18kAIC at 480V AC. It features line-and-load connections, metric mounting, and operates at 50/60 Hz.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Product Family: Series G
• Series: Series G
• Frame: EG Frame
• Type: EG
• Catalog No.: EGB3160AFG
• Current Rating: 160A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600Y/347V AC
• Interrupting Rating: 25kAIC @ 240V AC; 18kAIC @ 480V AC
• Protection Type: Thermal-Magnetic
• Trip Type: Adjustable Thermal, Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Connection Type: Line and Load
• Mounting Type: Metric
• Frequency: 50/60 Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EGB3160AFG
• Catalog Number: EGB3160AFG
• Model: EGB3160AFG
• Product Family: Eaton Series G Molded Case Circuit Breakers
• Series: Series G
• Frame: EG Frame
• Type: EG
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 160A
• Trip Configuration: Adjustable Thermal, Fixed Magnetic
• UPC:782116102426

Compatibility:

Designed for use with compatible Eaton Series G EG Frame electrical distribution equipment that accepts EG Series molded case circuit breakers. The EGB3160AFG provides 160A, 3-pole thermal-magnetic overcurrent protection for compatible 600Y/347V AC electrical distribution applications.

The breaker features line-and-load connections and metric mounting. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip characteristics, connection requirements, mounting arrangement, and installation specifications before installation.

Certifications:

• Eaton Series G
• EG Frame
• 160A Rated
• 3-Pole / 3-Phase
• 600Y/347V AC Rated
• 25kAIC @ 240V AC Interrupting Rating
• 18kAIC @ 480V AC Interrupting Rating
• Thermal-Magnetic Protection
• Adjustable Thermal Trip
• Fixed Magnetic Trip
• Complete Breaker
• Line and Load Connections
• Metric Mounting
• 50/60 Hz
