Square D EGB34025 Molded Case Circuit Breaker – 25A – 3-Pole – 480Y/277V AC – Thermal-Magnetic – Bolt-On – EGB Series

The Square D EGB34025 is a 25A, 3-pole bolt-on molded case circuit breaker designed for use with compatible Square D NF Panelboards. It features a thermal-magnetic trip unit and a signal indicator that provides an indication when a trip occurs.

The EGB34025 is rated for 480Y/277V AC and is calibrated for 40°C. It includes aluminum lugs with terminal ratings for 12–6 AWG aluminum and 14–6 AWG copper conductors. The breaker is CSA-rated, HID-rated, HACR-rated, and UL Listed as High-Intensity Discharge.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: EGB
• Series: EGB
• Catalog No.: EGB34025
• Current Rating: 25A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480Y/277V AC
• Protection Type: Thermal-Magnetic
• Trip Unit: Thermal-Magnetic
• Mounting Type: Bolt-On
• Application: Square D NF Panelboards
• Trip Indication: Signal Indicator
• Hold Current: 270A
• Trip Current: 875A
• Calibration: 40°C
• Terminal Type: Aluminum Lugs
• Aluminum Wire Range: AWG 12–6
• Copper Wire Range: AWG 14–6
• Brand: Square D
• Authenticity: Authentic Square D / Schneider Electric Product

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EGB34025
• Catalog Number: EGB34025
• Product Family: Square D EGB Circuit Breakers
• Series: EGB
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Bolt-On Molded Case Circuit Breaker
• Model: EGB34025
• Breaker Configuration: 3-Pole, 25A
• upc:
  785901311140

Compatibility:

Designed for use with compatible Square D NF Panelboards that accept EGB Series bolt-on molded case circuit breakers. The EGB34025 provides 25A, 3-pole protection for compatible 480Y/277V AC electrical distribution applications and includes aluminum lugs for copper or aluminum conductors within the specified wire ranges.

Always verify the specific panelboard model, approved breaker type, system voltage, pole configuration, available fault current, terminal requirements, conductor size, and installation requirements before installation.

Certifications:

• CSA Rated
• HID Rated
• HACR Rated
• UL Listed as High-Intensity Discharge
• 25A Rated
• 3-Pole / 3-Phase
• 480Y/277V AC Rated
• Thermal-Magnetic Protection
• Bolt-On Mounting
• 40°C Calibrated
• Genuine Square D / Schneider Electric Product
