Eaton EGH3030FFB Molded Case Circuit Breaker – 30A – 3-Pole / 3-Phase – 600Y/347V AC – 100kA @ 240V / 65kA @ 480V / 35kA @ 600Y/347V – Bolt-On – Series G EG

The Eaton EGH3030FFB is a 30A, 3-pole molded case circuit breaker from the Eaton Series G EG-Frame family. It is a complete breaker featuring fixed thermal and fixed magnetic trip protection for compatible electrical distribution applications.

The breaker is rated for 600Y/347V AC and provides interrupting ratings of 100kAIC at 240V AC, 65kAIC at 480V AC, and 35kAIC at 600Y/347V AC. It uses a bolt-on mounting configuration and operates at 50/60Hz.

Specifications:

• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Product Family: Series G
• Series: Series G
• Frame: EG-Frame
• Type: EG
• Catalog No.: EGH3030FFB
• Current Rating: 30A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600Y/347V AC
• Interrupting Rating: 100kAIC @ 240V AC; 65kAIC @ 480V AC; 35kAIC @ 600Y/347V AC
• Protection Type: Thermal-Magnetic
• Trip Type: Fixed Thermal, Fixed Magnetic
• Breaker Configuration: Complete Breaker
• Mounting Type: Bolt-On
• Frequency: 50/60Hz
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EGH3030FFB
• Catalog Number: EGH3030FFB
• Model: EGH3030FFB
• Product Family: Eaton Series G Molded Case Circuit Breakers
• Series: Series G
• Frame: EG-Frame
• Type: EG
• Brand: Eaton
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 30A
• UPC:786685381855

Compatibility:

Designed for use with compatible Eaton Series G EG-Frame electrical distribution equipment that accepts EG Series molded case circuit breakers. The EGH3030FFB provides 30A, 3-pole thermal-magnetic overcurrent protection for compatible 600Y/347V AC electrical distribution applications.

The breaker uses bolt-on mounting and provides fixed thermal and fixed magnetic protection. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, mounting arrangement, and installation requirements before installation.

Certifications:

• Eaton Series G
• EG-Frame
• 30A Rated
• 3-Pole / 3-Phase
• 600Y/347V AC Rated
• 100kAIC @ 240V AC
• 65kAIC @ 480V AC
• 35kAIC @ 600Y/347V AC
• Thermal-Magnetic Protection
• Fixed Thermal Trip
• Fixed Magnetic Trip
• Complete Breaker
• Bolt-On Mounting
• 50/60Hz
