Eaton Cutler-Hammer EGS3100AFG 100 Amp Molded Case Circuit Breaker – 3 Pole – 600Y/347 Vac – 85 kAIC – Series G

The Eaton Cutler-Hammer EGS3100AFG is a Series G molded case circuit breaker featuring an EG frame, a 100-ampere current rating, and adjustable thermal with fixed magnetic trip protection. Designed to protect compatible electrical distribution systems against overloads and short circuits, it is rated for 600Y/347 Vac. The breaker provides interrupting capacities of 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 22 kAIC at 600Y/347 Vac. It supports line and load connections and operates at 50/60 Hz.

Specifications

• Brand: Eaton
• Manufacturer: Cutler-Hammer
• MPN: EGS3100AFG
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame Type: EG frame
• Current Rating: 100 A
• Number of Poles: 3
• Trip Type: Adjustable thermal, fixed magnetic
• Voltage Rating: 600Y/347 Vac
• Interrupting Capacity at 240 Vac: 85 kAIC
• Interrupting Capacity at 480 Vac: 35 kAIC
• Interrupting Capacity at 600Y/347 Vac: 22 kAIC
• Connection Configuration: Line and load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Catalog Number: EGS3100AFG
• Model Number: EGS3100AFG
• Product Family: Eaton Cutler-Hammer Series G
• Frame Designation: EG
• Configuration: 3-pole, 100 A adjustable thermal/fixed magnetic MCCB
• UPC:782113503424

Compatibility

Suitable for compatible Eaton Cutler-Hammer Series G EG-frame applications requiring a 100 A, three-pole breaker with matching voltage and interrupting capacity.
