Eaton EGS3125AFG 125 Amp Molded Case Circuit Breaker – 3 Pole – 600Y/347 V AC – 35 kAIC@480 V AC – Adjustable Thermal, Fixed Magnetic – Series G

The Eaton EGS3125AFG is a 125 Amp, 3-pole molded case circuit breaker from the Eaton / Cutler-Hammer Series G, EG-frame product range. It is rated for 600Y/347 V AC and features adjustable thermal and fixed magnetic trip protection. The breaker provides multiple interrupting ratings depending on system voltage, uses line and load connections, and has a metric configuration.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series G
• Type: EG
• Frame: EG Frame
• Catalog Number / MPN: EGS3125AFG
• Primary Rating: 125 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600Y/347 V AC
• Interrupting Rating: 85 kAIC @ 240 V AC; 35 kAIC @ 480 V AC; 22 kAIC @ 600Y/347 V AC
• Trip Type: Adjustable Thermal / Fixed Magnetic
• Terminals: Line & Load Connections
• Configuration: Metric
• Frequency: 50/60 Hz

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: EGS3125AFG
• Series: Series G
• Type: EG
• Frame: EG Frame
• Current Rating: 125 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Trip Configuration: Adjustable Thermal / Fixed Magnetic
• Connection: Line and Load
• Configuration: Metric
• UPC:782113503431

Compatibility

The Eaton EGS3125AFG is intended for compatible Eaton / Cutler-Hammer Series G EG-frame electrical distribution and circuit protection applications.
