Eaton Cutler-Hammer EGS3160FFG 160 Amp Molded Case Circuit Breaker – 3 Pole – 600Y/347 Vac – Series G

The Eaton Cutler-Hammer EGS3160FFG is a Series G, EG-frame molded case circuit breaker rated at 160 A. It features fixed thermal and fixed magnetic trip protection and a three-pole configuration. The breaker provides interrupting capacities of 85 kAIC at 240 Vac, 35 kAIC at 480 Vac, and 22 kAIC at 600Y/347 Vac. It supports line- and load-side connections and operates at 50/60 Hz.

Specifications

• Brand: Eaton / Cutler-Hammer
• MPN: EGS3160FFG
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: Series G
• Frame: EG frame
• Rated Current: 160 A
• Number of Poles: 3
• Trip Type: Fixed thermal / fixed magnetic
• Rated Voltage: 600Y/347 Vac
• Interrupting Capacity at 240 Vac: 85 kAIC
• Interrupting Capacity at 480 Vac: 35 kAIC
• Interrupting Capacity at 600Y/347 Vac: 22 kAIC
• Connections: Line and load
• Measurement Standard: Metric
• Frequency: 50/60 Hz

Part Numbers & Identification

• Manufacturer: Eaton
• Brand Family: Cutler-Hammer
• Catalog Number: EGS3160FFG
• Frame Designation: EG
• Trip Configuration: Fixed thermal and fixed magnetic
• Current Rating: 160 A
• Pole Configuration: Three-pole
• UPC:782116896417

Compatibility

Suitable for Eaton Series G EG-frame applications requiring a three-pole, 160 A molded case circuit breaker with fixed thermal and fixed magnetic trip protection and line/load connections.
