Eaton EHD3015L Molded Case Circuit Breaker – 15A – 3-Pole / 3-Phase – 480V – 14kA @ 480V – Feed-Thru – Series C EHD

The Eaton EHD3015L is a 15A, 3-pole, 3-phase molded case circuit breaker from the Eaton Series C Type EHD Series. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The EHD3015L is rated for 480V and provides a 14kA interrupting rating at 480V, with a standard interrupting capacity. It features a feed-thru configuration and includes line-side and load-side lug terminals. The breaker is rated for operation at 40°C.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: EHD
• Type: EHD
• Catalog No.: EHD3015L
• Current Rating: 15A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V
• Interrupting Rating: 14kA @ 480V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Configuration: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EHD3015L
• Catalog Number: EHD3015L
• Model: EHD3015L
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: EHD
• Type: EHD
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 15A
• UPC:786679317051

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C EHD electrical distribution equipment that accepts EHD Series molded case circuit breakers. The EHD3015L provides 15A, 3-pole thermal-magnetic overcurrent protection for compatible 480V applications.

The breaker features a 14kA interrupting rating at 480V, non-interchangeable Long-Time and Instantaneous (LI) trip functions, feed-thru configuration, and line-side and load-side lug terminals.

Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C EHD Series
• 15A Rated
• 3-Pole / 3-Phase
• 480V Rated
• 14kA @ 480V Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Non-Interchangeable Trip
• Long-Time and Instantaneous (LI) Trip Functions
• Feed-Thru Configuration
• Line-Side and Load-Side Lug Terminals
• 40°C Rated
