Eaton EHD3050L Molded Case Circuit Breaker – 50A – 3-Pole – 480V AC – 14kA @ 480V AC – Feed-Thru – Series C EHD

The Eaton EHD3050L is a 50A, 3-pole, 3-phase molded case circuit breaker from the Eaton Cutler-Hammer Series C Type EHD. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The EHD3050L is rated for 480V AC with a 14kA interrupting rating at 480V AC. It features a feed-thru configuration and includes line- and load-side lug terminals for electrical connections.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: EHD
• Current Rating: 50A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V AC
• Interrupting Rating: 14kA @ 480V AC
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Trip Type: Non-Interchangeable
• Mounting / Configuration: Feed-Thru
• Terminal Configuration: Line- and Load-Side Lug Terminals
• Ambient Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer
• Authenticity: Authentic Eaton / Cutler-Hammer Product

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EHD3050L
• Catalog Number: EHD3050L
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: EHD
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Model: EHD3050L
• Breaker Configuration: 3-Pole, 50A
• upc:786679317150

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type EHD electrical distribution equipment that accepts EHD Series molded case circuit breakers. The EHD3050L provides 50A, 3-pole thermal-magnetic protection for compatible 480V AC applications and features Long-Time and Instantaneous (LI) trip functions.

The breaker includes line- and load-side lug terminals and uses a feed-thru configuration. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, terminal arrangement, and installation requirements before installation.

Certifications:

• Series C EHD
• 50A Rated
• 3-Pole / 3-Phase
• 480V AC Rated
• 14kA @ 480V AC Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip Functions
• Non-Interchangeable Trip
• Feed-Thru Configuration
• Line- and Load-Side Lug Terminals
• Genuine Eaton / Cutler-Hammer Product
