Eaton EHD3060 Molded Case Circuit Breaker – 60A – 3-Pole / 3-Phase – 480V – 14kA @ 480V – Feed-Thru – Series C EHD

The Eaton EHD3060 is a 60A, 3-pole, 3-phase molded case circuit breaker from the Eaton / Cutler-Hammer / Westinghouse Series C Type EHD. It is designed for compatible electrical distribution applications and provides thermal-magnetic overcurrent protection.

The EHD3060 is rated for 480V with a 14kA interrupting rating at 480V and features a standard interrupting capacity. It includes a non-interchangeable trip with Long-Time and Instantaneous (LI) trip functions, along with a feed-thru configuration and line-side and load-side lug terminals. The breaker is rated for operation at 40°C.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: EHD
• Catalog No.: EHD3060
• Current Rating: 60A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V
• Interrupting Rating: 14kA @ 480V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Connection / Configuration: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection

Part Numbers & Identification:

• Manufacturer Part Number (MPN): EHD3060
• Catalog Number: EHD3060
• Model: EHD3060
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: EHD
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 60A
• UPC:786679317167

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type EHD electrical distribution equipment that accepts EHD Series molded case circuit breakers. The EHD3060 provides 60A, 3-pole thermal-magnetic overcurrent protection for compatible 480V electrical distribution applications.

The breaker features a non-interchangeable LI trip, feed-thru configuration, and line-side and load-side lug terminals. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• No specific certification information provided
