Square D FAL34060 Molded Case Circuit Breaker – 60A – 3-Pole / 3-Phase – 480V – 18kA @ 480V – Feed-Thru – FAL Series

The Square D FAL34060 is a 60A, 3-pole, 3-phase thermal-magnetic molded case circuit breaker from the Square D PowerPact FAL Series. It is designed for compatible electrical distribution applications and provides standard interrupting capacity.

The FAL34060 is rated for 480V and provides an 18kA interrupting rating at 480V. It features a feed-thru configuration, is supplied as a complete breaker, and includes Long-Time and Instantaneous (LI) trip functions with line-side and load-side lug terminals.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: PowerPact
• Series: FAL
• Type: FAL
• Catalog No.: FAL34060
• Current Rating: 60A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 480V
• Interrupting Rating: 18kA @ 480V
• Interrupting Capacity: Standard
• Protection Type: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Mounting / Connection: Feed-Thru
• Breaker Configuration: Complete Breaker
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): FAL34060
• Catalog Number: FAL34060
• Model: FAL34060
• Product Family: Square D PowerPact Molded Case Circuit Breakers
• Series: FAL
• Type: FAL
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 60A
• Trip Configuration: Long-Time and Instantaneous (LI)
• UPC:785901423386

Compatibility:

Designed for use with compatible Square D PowerPact FAL Series electrical distribution equipment that accepts FAL Series molded case circuit breakers. The FAL34060 provides 60A, 3-pole thermal-magnetic overcurrent protection for compatible 480V electrical distribution applications.

The breaker features standard interrupting capacity, a feed-thru configuration, complete breaker construction, and line-side and load-side lug terminals. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip-unit requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• PowerPact FAL Series
• 60A Rated
• 3-Pole / 3-Phase
• 480V Rated
• 18kA @ 480V Interrupting Rating
• Standard Interrupting Capacity
• Thermal-Magnetic Protection
• Long-Time and Instantaneous (LI) Trip Functions
• Feed-Thru Configuration
• Complete Breaker
• Line-Side and Load-Side Lug Terminals
