Eaton FAZ-C50/3N 50 Amp Supplementary Circuit Protector – 3 Pole + Neutral – 15 kAIC – C Curve – FAZ Series

The Eaton FAZ-C50/3N is a 50 Amp supplementary circuit protector from the Eaton FAZ Series. Designed for industrial applications, this UL 1077 supplementary protector features a three-pole-plus-neutral configuration, a C-curve tripping characteristic, and a 15 kA interrupting rating. It is suitable for circuits with medium inrush current and operates at 50/60 Hz with standard terminals.

Specifications

• Manufacturer: Eaton
• Brand: Eaton Moeller
• Product Type: Supplementary Circuit Protector
• Series: FAZ
• Catalog Number / MPN: FAZ-C50/3N
• Primary Rating: 50 Amp
• Poles / Configuration: 3 Pole + Neutral
• Interrupting Rating: 15 kAIC
• Trip Curve: C Curve
• Magnetic Trip Range: 5–10 × In
• Frequency: 50–60 Hz
• Terminals: Standard Terminals
• Inrush Current Suitability: Medium Inrush Current
• Standard: UL 1077

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton Moeller
• Catalog Number: FAZ-C50/3N
• Series: FAZ
• Current Rating: 50 A
• Pole Count: 3 Pole + Neutral
• Product Type: Industrial Supplementary Circuit Protector
• Trip Curve: C Curve
• UPC:4015082789800

Compatibility

The Eaton FAZ-C50/3N is intended for compatible industrial control panels and supplementary overcurrent protection applications.

Certifications

• UL 1077
