GE FBV36TE020RV 20 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 150 kA@480 V – Bolt-On – Record Plus

The General Electric FBV36TE020RV is a 20 Amp, 3-pole, 3-phase molded case circuit breaker from the GE Record Plus Series, Type FBV, FB100 frame. It is rated for 600 V with a 150 kA interrupting rating at 480 V and features standard interrupting capacity. The breaker provides LI (Long-Time and Instantaneous) trip functions and includes load-side lug terminals and panel connections with a bolt-on connection.

Specifications

• Manufacturer: General Electric
• Brand: GE
• Product Type: Molded Case Circuit Breaker
• Series: Record Plus
• Type: FBV
• Frame: FB100
• Catalog Number / MPN: FBV36TE020RV
• Primary Rating: 20 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 150 kA @ 480 V
• Interrupting Capacity: Standard
• Trip Functions: LI – Long-Time and Instantaneous
• Connection / Mounting: Bolt-On
• Terminals: Load-Side Lug Terminals
• Panel Connections: Included

Part Numbers & Identification

• Manufacturer: General Electric
• Brand: GE
• Catalog Number: FBV36TE020RV
• Series: Record Plus
• Type: FBV
• Frame: FB100
• Current Rating: 20 A
• Pole Count: 3 Pole
• Product Type: Molded Case Circuit Breaker
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Bolt-On
• Terminals: Load-Side Lug Terminals
• Panel Connections: Included
• UPC:783164395006

Compatibility

The GE FBV36TE020RV is designed for compatible GE Record Plus Type FBV FB100-frame electrical distribution applications.
