Eaton FDB3025L 25 Amp Molded Case Circuit Breaker – 3 Pole – 600 VAC – 14 kA@480 VAC – Series C

The Eaton FDB3025L is a 25 Amp, 3-pole molded case circuit breaker from the Eaton Series C, F-Frame, Type FDB product range. Rated for 600 VAC and 250 VDC, it provides interrupting ratings of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC. The breaker features fixed thermal and fixed magnetic trip protection with line and load connections for compatible electrical distribution applications.

Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: FDB
• Frame: F-Frame
• Catalog Number / MPN: FDB3025L
• Primary Rating: 25 Amp
• Poles / Configuration: 3 Pole
• Voltage: 600 VAC
• DC Voltage: 250 VDC
• Interrupting Rating: 18 kAIC@240 VAC; 14 kAIC@480 VAC
• Trip Type: Thermal-Magnetic
• Trip Unit: Fixed Thermal, Fixed Magnetic
• Connection: Line and Load
• Frequency: 50/60 Hz

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Eaton
• Catalog Number: FDB3025L
• Series: Series C
• Type: FDB
• Frame: F-Frame
• Current Rating: 25 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit: Fixed Thermal, Fixed Magnetic
• Connection: Line and Load
• UPC: 786679399484

Compatibility

The Eaton FDB3025L is intended for compatible Eaton Series C F-Frame Type FDB electrical distribution equipment supporting its voltage and current ratings.
