Eaton FDC3060L 60A 3-Pole 600V Series C Molded Case Circuit Breaker Thermal Magnetic 100kA@480V

Product Description

The Eaton FDC3060L is a 60 Amp, 3-Pole Series C molded case circuit breaker designed for commercial and industrial power distribution systems. This F-Frame breaker features a thermal magnetic trip unit, current-limiting protection, and line/load terminals for reliable overcurrent protection in demanding applications. The FDC series is engineered for high interrupting capacity and dependable performance in switchboards, panelboards, and OEM equipment.

Key Features

• Catalog Number: FDC3060L
• Manufacturer: Eaton / Cutler-Hammer
• Amperage: 60 Amp
• Poles: 3-Pole
• Voltage Rating: 600VAC / 250VDC
• Series C F-Frame Breaker
• Thermal Magnetic Trip Unit
• Current Limiting Design
• Fixed Thermal / Fixed Magnetic Trip
• Line & Load Terminals Included
• Feed-Through Configuration
• UL Listed
• 50/60 Hz Rated

Interrupting Ratings (KAIC)

• 200kA @ 240VAC
• 100kA @ 480VAC

Technical Specifications

• Manufacturer: Eaton
• Catalog Number: FDC3060L
• Series: Series C
• Breaker Type: FDC
• Frame Size: F Frame
• Amperage: 60A
• Poles: 3
• Voltage Rating:
  • 600VAC
  • 250VDC
• Frequency: 50/60 Hz
• Trip Unit: Thermal Magnetic
• Trip Functions:
  • Long-Time (L)
  • Instantaneous (I)
• Terminal Type: Line & Load Lugs
• Configuration: Feed-Through
• Mounting Style: Panel Mount
• Certifications:
  • UL Listed
  • CSA Approved

Product Data

• Brand: Eaton
• Manufacturer: Eaton Corporation
• Model: FDC3060L
• Series: Series C
• Type: Molded Case Circuit Breaker
• Frame: F Frame
• Protection Type: Thermal Magnetic
• Mounting: Panel Mount
• Connection: Feed-Through
• Condition: New / Reconditioned
• Phase: 3 Phase
• UPC: 786679450109
• GTIN: 00786679450109
• Dimensions:
  • Height: 6.00 in
  • Width: 4.13 in
  • Depth: 3.38 in
• Weight: 4.5 lbs
• Country of Manufacture: Varies by Production Run

Compatible Equipment

• Eaton Series C Panelboards
• Eaton Switchboards
• Eaton Distribution Equipment
• OEM Power Distribution Assemblies Utilizing F-Frame Breakers

Applications

• Commercial Buildings
• Industrial Facilities
• Manufacturing Equipment
• Power Distribution Systems
• Motor Protection Applications
• OEM Electrical Equipment

Replacement Information

• Eaton Series C F-Frame Circuit Breaker
• Direct replacement should match catalog number FDC3060L
• Thermal Magnetic Fixed Trip Configuration
• Feed-Through Line & Load Terminal Design
