Eaton FDC3070 Molded Case Circuit Breaker – 70A – 3-Pole / 3-Phase – 600V – 100kA @ 480V – Feed-Thru – Series C FDC

The Eaton FDC3070 is a 70A, 3-pole, 3-phase molded case circuit breaker from the Eaton / Cutler-Hammer / Westinghouse Series C Type FDC. It features thermal-magnetic protection with Long-Time and Instantaneous (LI) trip functions and a non-interchangeable trip.

The FDC3070 is rated for 600V and provides a 100kA interrupting rating at 480V. It features current-limiting construction, a feed-thru configuration, and line- and load-side lug terminals. The breaker is rated for operation at 40°C and is supplied as a complete breaker.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: FDC
• Catalog No.: FDC3070
• Current Rating: 70A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 100kA @ 480V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Current Limiting: Current Limiting
• Connection / Configuration: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Temperature Rating: 40°C
• Breaker Configuration: Complete Breaker
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): FDC3070
• Catalog Number: FDC3070
• Model: FDC3070
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: FDC
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 70A
• Trip Configuration: Non-Interchangeable LI
• Rated Voltage: 600V
• Rated Current: 70A
• UPC:786679451540

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type FDC electrical distribution equipment that accepts FDC Series molded case circuit breakers. The FDC3070 provides 70A, 3-pole thermal-magnetic overcurrent protection for compatible 600V electrical distribution applications.

The breaker features current-limiting construction, a 100kA interrupting rating at 480V, feed-thru configuration, and line- and load-side lug terminals. It is supplied complete with a non-interchangeable LI trip. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, and installation requirements before installation.
