Eaton FDC3080 80 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 100 kA@480 V – Feed-Thru – Series C

The Eaton FDC3080 is an 80 Amp, 3-pole, 3-phase molded case circuit breaker from the Eaton / Cutler-Hammer Series C, Type FDC. It is rated for 600 V with a 100 kA interrupting rating at 480 V and features current-limiting, thermal-magnetic protection. The breaker has a non-interchangeable trip unit with LI (Long-Time and Instantaneous) trip functions and is designed for feed-thru applications with line and load-side lug terminals.

Specifications

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Product Type: Molded Case Circuit Breaker
• Series: Series C
• Type: FDC
• Catalog Number / MPN: FDC3080
• Primary Rating: 80 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 100 kA @ 480 V
• Interrupting Capacity: Current Limiting
• Trip Type: Thermal-Magnetic
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Ambient Temperature Rating: 40°C
• Connection / Mounting: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals

Part Numbers & Identification

• Manufacturer: Eaton
• Brand: Cutler-Hammer
• Catalog Number: FDC3080
• Series: Series C
• Type: FDC
• Current Rating: 80 A
• Pole Count: 3 Pole
• Product Type: Thermal-Magnetic Molded Case Circuit Breaker
• Trip Unit: Non-Interchangeable
• Trip Functions: LI – Long-Time and Instantaneous
• Connection: Feed-Thru
• Terminals: Line & Load-Side Lug Terminals
• UPC:786679451564

Compatibility

The Eaton FDC3080 is designed for compatible Eaton / Cutler-Hammer Series C Type FDC electrical distribution applications.
