Eaton FDC3200 Molded Case Circuit Breaker – 200A – 3-Pole / 3-Phase – 600V – 100kA @ 480V – Feed-Thru – Series C FDC

The Eaton FDC3200 is a 200A, 3-pole, 3-phase molded case circuit breaker from the Eaton / Cutler-Hammer / Westinghouse Series C Type FDC. It features thermal-magnetic protection with a non-interchangeable Long-Time and Instantaneous (LI) trip.

The FDC3200 is rated for 600V and provides a 100kA interrupting rating at 480V. It features a current-limiting design, a feed-thru configuration, and line-side and load-side lug terminals. The breaker is rated for operation at 40°C.

Specifications:

• Manufacturer: Eaton / Cutler-Hammer / Westinghouse
• Product Type: Molded Case Circuit Breaker
• Product Family: Series C
• Series: Series C
• Type: FDC
• Catalog No.: FDC3200
• Current Rating: 200A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 100kA @ 480V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Trip Type: Non-Interchangeable
• Trip Functions: Long-Time and Instantaneous (LI)
• Current Limiting: Current Limiting
• Mounting / Configuration: Feed-Thru
• Terminal Type: Line-Side and Load-Side Lug Terminals
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Eaton / Cutler-Hammer

Part Numbers & Identification:

• Manufacturer Part Number (MPN): FDC3200
• Catalog Number: FDC3200
• Model: FDC3200
• Product Family: Eaton Series C Molded Case Circuit Breakers
• Series: Series C
• Type: FDC
• Brand: Eaton / Cutler-Hammer
• Manufacturer: Eaton
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 200A
• UPC:786679019597

Compatibility:

Designed for use with compatible Eaton / Cutler-Hammer Series C Type FDC electrical distribution equipment that accepts FDC Series molded case circuit breakers. The FDC3200 provides 200A, 3-pole thermal-magnetic overcurrent protection for compatible 600V electrical distribution applications.

The breaker features a non-interchangeable LI trip, current-limiting design, feed-thru configuration, and line-side and load-side lug terminals. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, trip requirements, terminal arrangement, and installation requirements before installation.

Certifications:

• No specific certification information provided
