Square D FH360351021 Molded Case Circuit Breaker – 35A – 3-Pole / 3-Phase – 600V – 65kA @ 240V / 25kA @ 480V / 18kA @ 600V – I-Line Style Plug-In – Type FH

The Square D FH360351021 is a 35A, 3-pole, 3-phase thermal-magnetic molded case circuit breaker from the Square D / Schneider Electric I-Line Type FH Series. It is designed for compatible electrical distribution and overcurrent protection applications.

The FH360351021 is rated for 600V and provides a high interrupting rating of 65kA at 240V, 25kA at 480V, and 18kA at 600V. It features an I-Line style plug-in connection, is rated for operation at 40°C, and includes a 120/240VAC shunt trip.

Specifications:

• Manufacturer: Square D / Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Product Family: I-Line
• Series: I-Line
• Type: FH
• Catalog No.: FH360351021
• Current Rating: 35A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V
• Interrupting Rating: 65kA @ 240V; 25kA @ 480V; 18kA @ 600V
• Interrupting Capacity: High
• Protection Type: Thermal-Magnetic
• Connection / Mounting: I-Line Style Plug-In
• Shunt Trip: 120/240VAC
• Temperature Rating: 40°C
• Application: Electrical Distribution and Overcurrent Protection
• Brand: Square D / Schneider Electric

Part Numbers & Identification:

• Manufacturer Part Number (MPN): FH360351021
• Catalog Number: FH360351021
• Model: FH360351021
• Product Family: Square D I-Line Circuit Breakers
• Series: I-Line
• Type: FH
• Brand: Square D
• Manufacturer: Schneider Electric
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 35A
• Rated Voltage: 600V
• Shunt Trip: 120/240VAC
• UPC:785901112488

Compatibility:

Designed for use with compatible Square D / Schneider Electric I-Line electrical distribution equipment that accepts Type FH I-Line style plug-in molded case circuit breakers. The FH360351021 provides 35A, 3-pole thermal-magnetic overcurrent protection for compatible 600V electrical distribution applications.

The breaker uses an I-Line style plug-in connection and includes a 120/240VAC shunt-trip function. Always verify the specific panelboard or electrical equipment model, approved breaker type, system voltage, available fault current, pole configuration, I-Line compatibility, shunt-trip requirements, and installation specifications before installation.

Certifications:

• I-Line Type FH Series
• 35A Rated
• 3-Pole / 3-Phase
• 600V Rated
• 65kA @ 240V Interrupting Rating
• 25kA @ 480V Interrupting Rating
• 18kA @ 600V Interrupting Rating
• High Interrupting Capacity
• Thermal-Magnetic Protection
• I-Line Style Plug-In
• 120/240VAC Shunt Trip
• 40°C Rated
