Siemens FXD63A150 150 Amp Motor Circuit Protector – 3 Pole – 600 V – 35 kA@480 V – Bolt-On – SENTRON Series

The Siemens FXD63A150 is a 150 Amp, 3-pole motor circuit protector (MCP) from the Siemens SENTRON Series, Type FXD. It is rated for 600 V with a 35 kA interrupting capacity at 480 V and provides instantaneous-only magnetic protection. The breaker features a standard instantaneous range with an adjustable magnetic range of 800–1500 A. It is designed for bolt-on mounting, and lugs are not included.

Specifications

• Manufacturer: Siemens
• Brand: Siemens
• Product Type: Motor Circuit Protector (MCP)
• Series: SENTRON
• Type: FXD
• Catalog Number / MPN: FXD63A150
• Primary Rating: 150 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V
• Interrupting Rating: 35 kA @ 480 V
• Interrupting Capacity: Standard
• Protection Type: Magnetic Only
• Trip Function: I – Instantaneous
• Instantaneous Range: Standard
• Magnetic Range: 800–1500 A
• Connection / Mounting: Bolt-On
• Terminals / Lugs: Not Included
• Application: Motor Circuit Protector (MCP)

Part Numbers & Identification

• Manufacturer: Siemens
• Brand: Siemens
• Catalog Number: FXD63A150
• Series: SENTRON
• Type: FXD
• Current Rating: 150 A
• Pole Count: 3 Pole
• Product Type: Motor Circuit Protector
• Protection: Magnetic Only
• Trip Function: I – Instantaneous
• Magnetic Range: 800–1500 A
• Terminals / Lugs: Not Included
• UPC: 783643212275

Compatibility

The Siemens FXD63A150 is designed for compatible Siemens SENTRON Type FXD motor circuit protector applications. Verify the specific motor starter, panelboard or switchboard, system voltage, mounting configuration, magnetic trip requirements, and breaker compatibility before installation.
