Siemens FXD63A250 Molded Case Circuit Breaker – 250A – 3-Pole / 3-Phase – 600V AC – 65kA @ 240V – Bolt-On – Sentron FXD6 Series

The Siemens FXD63A250 is a 250A, 3-pole, 3-phase molded case circuit breaker from the Siemens Sentron FXD6 Series. It features thermal-magnetic protection for overload and short-circuit protection in compatible industrial and commercial electrical distribution applications.

The breaker is rated for 600V AC and provides interrupting ratings of 65kAIC at 240V AC, 35kAIC at 480V AC, and 22kAIC at 600V AC. It supports bolt-on mounting and operates at 50/60Hz.

Specifications:

• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Product Family: Sentron
• Series: FXD6
• Type: FXD
• Catalog No.: FXD63A250
• Current Rating: 250A
• Number of Poles: 3-Pole
• Phase: 3-Phase
• Voltage Rating: 600V AC
• Interrupting Rating: 65kAIC @ 240V AC; 35kAIC @ 480V AC; 22kAIC @ 600V AC
• Protection Type: Thermal-Magnetic
• Mounting Type: Bolt-On
• Frequency Rating: 50/60Hz
• Connection Type: Line/Load Lug or Bolt-On Style, Depending on Configuration
• Application: Industrial and Commercial Electrical Distribution
• Trip Unit: Thermal-Magnetic

Part Numbers & Identification:

• Manufacturer Part Number (MPN): FXD63A250
• Catalog Number: FXD63A250
• Model: FXD63A250
• Product Family: Siemens Sentron Circuit Breakers
• Series: FXD6
• Type: FXD
• Brand: Siemens
• Manufacturer: Siemens
• Product Type: Molded Case Circuit Breaker
• Breaker Configuration: 3-Pole, 250A
• UPC / GTIN: 783643212282

Compatibility:

Designed for use with compatible Siemens Sentron FXD6 Series panelboards, switchboards, and electrical distribution equipment that accepts FXD Series molded case circuit breakers. The FXD63A250 provides 250A, 3-pole thermal-magnetic protection for compatible 600V AC electrical distribution applications.

The source information identifies bolt-on mounting and line/load lug or bolt-on style connections depending on configuration. Always verify the specific equipment model, approved breaker configuration, system voltage, available fault current, pole configuration, terminal arrangement, mounting requirements, and installation specifications before installation.

Certifications:

• UL 489
• IEC 60947-2
• HACR Rated
• Sentron FXD6 Series
• 250A Rated
• 3-Pole / 3-Phase
• 600V AC Rated
• 65kAIC @ 240V AC Interrupting Rating
• 35kAIC @ 480V AC Interrupting Rating
• 22kAIC @ 600V AC Interrupting Rating
• Thermal-Magnetic Protection
• Bolt-On Mounting
• 50/60Hz
