GE TEY130 30 Amp 1 Pole Thermal Magnetic Circuit Breaker – Bolt-On – 120/240/277V AC

In stock
SKU: TEY130 GTIN/UPC: 783164180930
$93.80
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The GE TEY130 30 Amp single-pole circuit breaker is designed for reliable commercial and industrial branch circuit protection. Part of the GE TEY TEY frame compact series, it features a thermal-magnetic LI (Long-Time and Instantaneous) trip mechanism that provides dependable protection against overloads and short circuits. Its bolt-on mounting design ensures a secure installation in compatible panelboards, while the compact construction helps save space. With a high interrupt rating of 65kA at 120V, this breaker is suitable for demanding electrical environments requiring strong fault current protection.

Voltage and Rating

  • Current Rating: 30 Amps
  • Voltage Rating: 120/240/277V AC
  • Frequency Rating: 50/60 Hz
  • Interrupting Capacity: 65 kA @ 120V, 14 kA @ 240V/277V
  • Phase: 1 Phase

Key Specifications

  • Breaker Type: Thermal Magnetic Circuit Breaker
  • Trip Type: LI (Long-Time & Instantaneous), Non-Interchangeable
  • Number of Poles: 1-Pole
  • Frame: TEY
  • Actuator Type: Pivot/Toggle Handle
  • Mounting Type: Bolt-On
  • Series/Type: Compact TEY Series
  • Application: Commercial and industrial branch circuit protection
  • Compatible Connection: Load Lug

Technical Specifications

  • Wire Size Range: 14 to 2/0 AWG
  • Terminal Type: Load Lug
  • Temperature Rating: 40°C
  • Material: Plastic housing
  • Trip Technology: Thermal Magnetic
  • Frequency: 50/60 Hz
  • Construction Features: Non-interchangeable trip, compact design

Product Data

  • Manufacturer: GE (General Electric)
  • MFG Part Number: TEY130
  • McMc Part Number: GEDITEY130
  • UPC: 783164180930

Dimensions

  • Height: 5-1/4 in
  • Width: 1 in
  • Depth: 3-1/16 in
  • Type Thermal Magnetic
  • Vendor GE
  • Brand General Electric
