GE THQLT2020 20A/20A 2x1P Tandem Circuit Breaker – Plug-In – 120/240V

The GE Q-Line THQLT2020 tandem circuit breaker provides reliable 20A/20A, 2x1-pole protection for residential 120/240V circuits. Designed for GE PowerMark load centers, its compact, space-saving design allows two circuits in the footprint of a single standard breaker. With plug-in installation and UL listing, this breaker ensures safe, efficient, and convenient residential circuit protection.

Voltage and Rating

• Amperage: 20A / 20A
• Voltage Rating: 120/240 Volts AC
• Interrupting Capacity: 10 kAIC
• Frequency: 50/60 Hz

Key Specifications

• Breaker Type: Tandem Circuit Breaker
• Poles: 2x1P
• Mounting Type: Plug-In
• Product Range: Q-Line
• Application: Residential branch circuit protection
• Compatible Panels: GE PowerMark load centers

Technical Specifications

• Wire Size: (2) #14–8 AWG Copper / #12–8 AWG Aluminum
• Terminal Tightening Torque: 25 lb-in
• Connection Terminals: Plug-in
• Certifications: UL Listed, HACR Rated, SWD Rated

Product Data

• Manufacturer: ABB Electrification Canada ULC
• Brand: GE
• Model Number: THQLT2020
• UPC: 783164681352

Dimensions

• • Height: 3.28 in
  • Width: 1.0 in
  • Depth: 2.38 in
  • Weight: 0.419 lbs
