GE

General Electric FBV36TE045RV Molded Case Circuit Breaker – 3 Pole, 45A, Record Plus Series

In stock
SKU: FBV36TE045RV GTIN/UPC: 783164395051
$764.10
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The General Electric FBV36TE045RV is a molded case circuit breaker from the GE Record Plus series, engineered for commercial and industrial three-phase power distribution systems. Built on the FB100 frame platform, this breaker delivers dependable thermal magnetic protection with long-time and instantaneous trip functions. Its bolt-on mounting design and high interrupting capacity make it suitable for demanding electrical applications.

Key Specifications

  • Manufacturer: General Electric
  • Part Number: FBV36TE045RV
  • Product Type: Molded Case Circuit Breaker
  • Series: Record Plus
  • Type: FBV
  • Frame Type: FB100
  • Poles: 3
  • Phase: 3
  • Current Rating: 45A
  • Voltage Rating: 600V
  • Protection Type: Thermal Magnetic
  • Trip Functions: LI – Long-Time and Instantaneous
  • Interrupting Capacity: 150kA @ 480V

Installation & Connections

  • Connection Type: Bolt-On
  • Includes:
    • Load side lug terminals
    • Panel connections
  • Trip Characteristics: Fixed thermal magnetic

Physical Details

  • Dimensions (H × W × D): 4.25 × 1.25 × 6.5 in
  • Weight: 7 lb

Certifications

  • CSA Approved

Product Applications

  • Commercial electrical distribution systems
  • Industrial power panels
  • Three-phase branch circuit protection
  • Motor and equipment protection
  • High fault current applications
  • Type Circuit Breakers
  • Vendor GE
  • Brand General Electric
