General Electric FBV36TE060RV Molded Case Circuit Breaker – 3 Pole, 60A, Type FBV

In stock
SKU: FBV36TE060RV GTIN/UPC: 783164395075
$764.10
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The General Electric FBV36TE060RV is a molded case circuit breaker designed for commercial and industrial three-phase electrical distribution systems. Built on the FB100 frame platform, this breaker provides dependable thermal magnetic protection with long-time and instantaneous trip functions. Its panel-mounted design with load lug and panel connections ensures secure installation and reliable circuit protection in demanding applications.

Key Specifications

  • Manufacturer: General Electric
  • Part Number: FBV36TE060RV
  • McMc Part Number: GEDIFBV36TE060RV
  • Product Type: Molded Case Circuit Breaker
  • Type: FBV
  • Frame Type: FB100
  • Number of Poles: 3
  • Phase: 3 Phase
  • Current Rating: 60A
  • Voltage Rating: 600Y/347VAC
  • Frequency Rating: 50/60 Hz
  • Trip Type: LI / Thermal Magnetic
  • Actuator Type: Pivot/Toggle Handle
  • Connection Type: Load Lug / Panel
  • Mounting Type: Panel
  • Material: Plastic
  • Wire Size: 10–4 AWG

Interrupting Ratings

  • 35/65 kA

Physical Details

  • Dimensions (W × D × H): 4.11 × 3.28 × 6.45 in
  • Operating Temperature: -40°C to 80°C

Identification

  • UPC: 783164395075

Product Applications

  • Commercial electrical distribution systems
  • Industrial panelboards
  • Three-phase branch circuit protection
  • Motor and equipment protection
  • High fault current electrical applications
  • Type Circuit Breakers
  • Vendor GE
  • Brand General Electric
