General Electric GE THJK636500WL 500A 3 Pole Molded Case Circuit Breaker – Bolt On – 600VAC

In stock
SKU: THJK636500WL-NS GTIN/UPC: 783164131048
$4,599.00
Condition
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The General Electric GE THJK636500WL is a robust molded case circuit breaker engineered for superior protection in demanding commercial and industrial power systems. As part of the THJK Hi-Break J-frame series, this breaker is equipped with a thermal magnetic interchangeable trip unit that delivers dependable overload and short circuit protection. With a 500 ampere current rating, 3-pole design, and bolt-on mounting configuration, it is ideal for switchgear, feeders, panelboards, and high-capacity distribution applications operating up to 600VAC.

Product Specifications

  • Brand: General Electric GE
  • Model: THJK636500WL
  • Amperage: 500 Ampere
  • Number of Poles: 3 Pole
  • Breaker Type: Molded Case Circuit Breaker
  • Mount Type: Bolt On
  • Frame Style: THJK Hi-Break J Frame
  • Trip Unit Type: Thermal Magnetic Interchangeable Trip Unit

Technical Specifications

  • Operating Temperature: 40 Degree Celsius
  • Frequency: 50/60Hz
  • Connection Type: Bolt On
  • Terminal Type: Line and Load End Terminals Standard
  • Lug Type: Standard Line and Load
  • Trip Setting Range: 1500-5000
  • Protection Type: Overload and Short Circuit Protection
  • Application: Industrial Distribution Systems, Commercial Panels, Feeders, Equipment Protection

Voltage and Ratings

  • Rated Voltage: 600VAC Maximum
  • Interrupting Rating @ 240V AC: 65 Kiloampere
  • Interrupting Rating @ 480V AC: 35 Kiloampere
  • Interrupting Rating @ 600V AC: 25 Kiloampere
  • Interrupting Rating @ 250V DC: 40 Kiloampere

Product Data

  • Manufacturer: General Electric GE
  • Condition: New / Reconditioned (Depending Supply)
  • Warranty: One Year
  • Availability: Subject to Stock
  • Frame Type: J
  • SKU / UPC: Available on Request

Important Note

Accessories ordered with the breaker may be installed prior to shipment at no additional cost depending on supplier policy. Always confirm amperage, trip setting range, voltage ratings, terminal type, and compatibility with your electrical system before purchase or installation.
