General Electric SEHA36AT0100 100A 3-Pole Molded Case Circuit Breaker – Bolt-On Mount – 600VAC

The General Electric SEHA36AT0100 is a durable and dependable molded case circuit breaker designed for commercial and industrial power distribution systems requiring reliable overload and short-circuit protection. Built on the SE150 frame platform, this 3-pole breaker features a thermal magnetic non-interchangeable trip unit with a maximum current rating of 100 amperes at 40°C. Its bolt-on mounting configuration provides secure installation, while its high interrupting capacity ensures dependable protection under fault conditions. This breaker is suitable for a wide range of panelboard and switchgear applications operating up to 600VAC.

Product Specifications

• Brand: General Electric
• Model: SEHA36AT0100
• Amperage: 100 Amp (Maximum)
• Number of Poles: 3 Pole
• Breaker Type: Molded Case Circuit Breaker
• Mount Type: Bolt-On
• Voltage: 600VAC
• Frequency: 50/60 Hz
• Frame Type: E / SE150 Frame Style
• Warranty: One Year

Technical Specifications

• Trip Unit Type: Thermal Magnetic Non-Interchangeable
• Protection Type: Overload and Short Circuit Protection
• Frame Style: SE150
• Connection Type: Bolt-On
• Standard Lug Type: No Lugs Included
• Operating Temperature Rating: 40°C
• Industrial Construction: Heavy-Duty Performance Design
• Application: Commercial and Industrial Distribution Systems

Voltage and Ratings

• 65 kA @ 240V AC
• 25 kA @ 480V AC
• 18 kA @ 600V AC
• Maximum Rated Voltage: 600VAC
• Frequency Rating: 50/60 Hz

Product Data

• Manufacturer: General Electric GE
• Part Number: SEHA36AT0100
• Condition: New Surplus / Certified Reconditioned (varies by stock)
• Poles: 3
• Mounting Style: Bolt-On
• Terminals Included: No
• Rating Plug Required: Yes
• Warranty Coverage: 1 Year In-House Warranty
• Suitable For: Panelboards, Switchboards, Industrial Systems

Important Note

This unit requires a compatible rating plug in order to function properly. No terminals or lugs are included with the breaker. Please verify compatibility with your panel, frame type, voltage system, and trip requirements before purchase. Installation should be completed by a qualified electrician following applicable electrical codes and safety procedures.
