General Electric SELA36AI0150 Molded Case Circuit Breaker – 150A, 3 Pole, Spectra Series

The General Electric SELA36AI0150 is a Spectra Series molded case circuit breaker designed for high interrupting capacity protection in industrial and commercial power distribution systems. Built on the SELA frame platform, this 3-pole, 3-phase breaker is a magnetic-only (instantaneous trip) device, providing fast response protection for fault conditions. It is suitable for use in bolt-on Spectra Series switchboards and panelboards where high-speed short-circuit protection is required.

Key Specifications

• Manufacturer: General Electric
• Part Number: SELA36AI0150
• Series: Spectra Series
• Product Type: Molded Case Circuit Breaker (MCCB)
• Frame Type: SELA
• Current Rating: 150A
• Voltage Rating: 600V
• Phase: 3 Phase
• Poles: 3

Protection & Trip Features

• Protection Type: Magnetic Only
• Trip Function: Instantaneous (I only)
• Magnetic Range: 11–90A
• Current Limiting: Yes
• Reverse Feed Compatible: Yes

Interrupting Capacity

• 65kA @ 480V

Installation & Connection

• Mounting Type: Bolt-On
• Connection Type: Bolt-On
• Lugs: Not included

Physical Specifications

• Dimensions (H × W × D): 6.31" × 4.12" × 3.38"
• Weight: 6 lbs

Applications

• GE Spectra Series panelboards and switchboards
• Industrial high-fault-current protection systems
• Motor circuit protection (MCP applications)
• Short-circuit protection in distribution systems
• Commercial electrical infrastructure
