The General Electric SL361RG is a Spectra Series fusible bus plug designed for reliable circuit protection and power distribution in commercial and industrial busway systems. Rated at 30 Amps and configured with 3 poles for three-phase applications, this fusible style bus plug is engineered for use with Spectra low-amp aluminum and copper busway systems. With a high interrupting rating of 200kA at 480V, the SL361RG provides dependable performance and enhanced protection in demanding electrical environments.
Voltage and Rating
- Current Rating: 30 Amps
- Voltage Rating: 600V
- Interrupting Rating: 200kA @ 480V
Key Specifications
- Brand: General Electric
- Series: Spectra
- Product Type: Fusible Bus Plug
- Number of Poles: 3-Pole
- Phase: 3-Phase
- Number of Wires: 3
Technical Specifications
- Fusible Style Construction
- Suitable for Spectra Low-Amp Aluminum & Copper Busway Systems
- High Interrupting Capacity Design
- Heavy-Duty Industrial Performance
Dimensions
- Length: 13 in
- Width: 11.25 in
Standards & Approvals
- UL Approved
- CSA Approved
Product Data
- Manufacturer: General Electric
- Part Number: SL361RG
- UPC: 783175980437
- GTIN: 783175980437
Applications
- Spectra busway systems
- Commercial electrical distribution
- Industrial power systems
- Three-phase feeder circuits
- Busway power tap applications
- Type plug
- Vendor GE
- Brand General Electric
