General Electric TED124090 90A 2-Pole Thermal Magnetic Circuit Breaker – Bolt-On – 480VAC

The General Electric TED124090 is an E150 Series molded case circuit breaker designed for dependable overcurrent and short-circuit protection in industrial and commercial power distribution systems. Rated at 90 Amps with a 2-pole configuration, this breaker is built for installation in GE A-Series and Spectra Series panelboards, switchboards, and motor control centers. It provides reliable protection for 480VAC systems using thermal magnetic LI (Long-Time, Instantaneous) trip technology.

Voltage and Rating

• Current Rating: 90 Amps
• Voltage Rating: 480VAC
• Interrupting Rating: 18 kAIC @ 480VAC

Key Specifications

• Catalog Number: TED124090
• Brand: General Electric
• Product Type: Molded Case Circuit Breaker
• Product Line: E150 / E-Frame
• Frame Type: E-Frame
• Number of Poles: 2-Pole
• Mounting Style: Bolt-On
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI (Long-Time, Instantaneous)
• Protection Type: Thermal Magnetic

Protection Features

• Reliable overload and short-circuit protection
• Fixed thermal and instantaneous trip settings
• Designed for AC power distribution systems
• Trip-free mechanism for enhanced safety
• Suitable for reverse feed applications

Technical Features

• Heavy-duty molded case construction
• Compatible with GE E-Frame panelboards and switchboards
• Industrial-grade durability
• Non-interchangeable trip design

Connection & Wiring

• Terminal Type: Bolt-on lugs
• Cu/Al compatibility depends on configuration (WL options where applicable)

Certifications & Standards

• UL 489
• CSA Certified
• HACR Rated (where applicable)

Applications

• Industrial electrical distribution systems
• Commercial panelboards and switchboards
• Motor control centers (MCCs)
• HVAC and equipment branch circuits
• General-purpose 480VAC protection systems
