GE

General Electric TED136150 150A 3-Pole Thermal Magnetic Circuit Breaker – Bolt-On – 600VAC

In stock
SKU: TED136150 GTIN/UPC: 783164132960
$1,100.25
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The General Electric TED136150 is an E150 Series molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial electrical distribution systems. Rated at 150 Amps with a 3-pole configuration, this breaker is built for installation in GE A-Series and Spectra Series panelboards, switchboards, and motor control centers. It delivers dependable protection for three-phase circuits operating up to 600VAC, making it suitable for heavy-duty electrical distribution applications.

Voltage and Rating

  • Current Rating: 150 Amps
  • Voltage Rating: 600VAC
  • Interrupting Rating: Based on E-Frame system rating (application dependent)

Key Specifications

  • Catalog Number: TED136150
  • Brand: General Electric
  • Product Type: Thermal Magnetic Circuit Breaker
  • Product Line: E150 / E-Frame
  • Frame Type: E-Frame
  • Number of Poles: 3-Pole
  • Mounting Style: Bolt-On
  • Trip Technology: Thermal Magnetic
  • Trip Function: LI (Long-Time, Instantaneous)
  • Suitable for Reverse Feed: Yes

Protection Features

  • Thermal magnetic overcurrent protection
  • Fixed long-time and instantaneous trip settings
  • Reliable fault interruption performance
  • Suitable for AC electrical systems
  • Trip-free mechanism for enhanced safety

Connection & Wiring

  • Terminal Type: Lugs (configuration varies by WL/suffix options)
  • Cu/Al compatible where applicable
  • Designed for standard E-Frame accessory systems

Technical Features

  • Heavy-duty molded case construction
  • Industrial-grade durability
  • Compatible with GE A-Series and Spectra Series equipment
  • Non-interchangeable trip design

Certifications & Standards

  • UL 489
  • CSA Certified
  • Suitable for service equipment (where applicable)

Applications

  • Industrial power distribution systems
  • Motor control centers (MCCs)
  • Commercial switchboards and panelboards
  • HVAC and heavy equipment circuits
  • Three-phase electrical distribution systems
  • Type Thermal Magnetic
  • Vendor GE
  • Brand General Electric
