The General Electric TED136YT100 is an E150 Series molded case device configured as a dummy trip unit, designed for use in GE A-Series and Spectra Series panelboards and switchboards. Rated at 100 Amps with a 3-pole configuration, this device is used where a breaker-style form factor is required but without active thermal or magnetic tripping functionality. It is intended for system configuration, load balancing, or placeholder applications within approved electrical assemblies.
Voltage and Rating
- Current Rating: 100 Amps
- Voltage Rating: 600VAC
- Device Function: Dummy Trip (no protective tripping function)
Key Specifications
- Catalog Number: TED136YT100
- Brand: General Electric
- Product Type: Dummy Trip / Non-Protective Device
- Product Line: E150 / E-Frame
- Frame Type: E-Frame
- Number of Poles: 3-Pole
- Mounting Style: Bolt-On
- Function Type: Non-protective (no overcurrent protection)
Protection Features
- No thermal or magnetic protection
- Used in place of active breaker modules in specific configurations
- Maintains mechanical compatibility within E-Frame systems
Technical Features
- Heavy-duty molded case construction
- Compatible with GE panelboard and switchboard systems
- Designed for system flexibility and configuration matching
- Maintains physical breaker footprint
Connection & Wiring
- Terminal Type: Lugs (system dependent)
- Compatible with E-Frame accessories (where applicable)
Certifications & Standards
- UL Listed (system dependent configuration)
- CSA Certified (where applicable)
Applications
- Panelboard configuration balancing
- Electrical assembly placeholder positions
- System design requiring non-active breaker positions
- GE A-Series and Spectra Series equipment setups
- Type Thermal Magnetic
- Vendor GE
- Brand General Electric
