General Electric TEL1360100WL – 3‑Pole 100 A 600 V AC Molded Case Breaker, Thermal‑Magnetic, 65 kAIC @ 480 V

Product Title

General Electric TEL1360100WL – 3‑Pole 100 A 600 V AC Molded Case Breaker, Thermal‑Magnetic, 65 kAIC @ 480 V

Product Description

The General Electric TEL1360100WL is a 3‑pole, 100 Amp, 600 V AC molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial electrical distribution systems. Part of GE’s TEL series, this breaker features a thermal‑magnetic trip unit with fixed Long-Time (LI) and Instantaneous protection, providing dependable performance under overload and short-circuit conditions.

With a 65 kAIC @ 480 V AC interrupting rating, the TEL1360100WL is suitable for branch and feeder circuit protection in panelboards, switchboards, and other distribution equipment where high fault current capability is required.

Key Features

• Poles: 3

• Amperage: 100 A

• Voltage: 600 V AC (maximum)

• Type: Molded Case Circuit Breaker (TEL Series)

• Thermal-magnetic trip with Long-Time (LI) and Instantaneous protection

• Interrupting capacity: 65 kAIC @ 480 V AC

• Designed for commercial and industrial power distribution

Technical Specifications

• Manufacturer: General Electric

• Catalog Number: TEL1360100WL

• Series / Frame: TEL

• Phase: Three‑Phase

• Trip Type: Thermal-Magnetic (LI & Instantaneous)

• Voltage Rating: 600 V AC

• Interrupting Rating: 65 kAIC @ 480 V AC

• Frequency Rating: 50/60 Hz

• Connection Type: Feed-Thru / Lug Terminals

• Protection: Overload and short-circuit

Product Data

• UPC / GTIN: Not Assigned by Manufacturer

• Application: Industrial and commercial electrical distribution

• Certifications: UL Listed

• Compatibility: GE TEL-series panelboards and distribution systems
